- The Chroma 8000 ATS support team not only helps to plan and develop the ATS, but they also provide their expertise to tailor a test fixture to the customer’s needs. Battery Pack Test: Chroma provides two software modules that integrate a DC power supply and an electronic load for battery pack testing.
- Digital Power Meter/Analyzer: Chroma series 7. System Power Panel 8. Connecting Panel 9. DC Power Supply: 62000H series 10. RLC Load: Chroma A800067 Model 8000 High Performance Hardware Devices and Software Architecture PV Inverter Automated Test Systems 4 6 5 8 7 9 1 2 3 10.
- The Chroma 8000 ATS is a standard test platform that resolves problems brought on by conventional self-designed systems for power electronics testing. Designed with an open architecture, the Chroma 8000 ATS includes a wide range of hardware choices such as AC/DC power supplies, Electronic Loads, Power Analyzers, Oscilloscopes, Digital multi.
Green Screen Photo Software for both Mac and PC, This Chroma Key Software can eaisly replace the green on a page with any background. Lightroom Link as well. Most Popular Green Screen Photography Software over 30,000 users (Chroma Key Photo Software) for Replacing Green Screen Backgrounds on Photos.
SMPS Automatic Test System moddel 8000
Click to view in PDF format (1739 KB)
- Open architecture software
- Expandable hardware support
- Support GPIB instruments & RS232orRS485/I²C/CAN BUS interface
- User editable test iteam
- User editable test programs
- User editable report format
- Statistic report
- On-Line control function
- User authority control
- Release control
- Activity log
- Master/Slave control mode
- Multi-UUT test capability for single-output PSU
- Support barcode reader
- Support shop-floor control
- Remote monitoring via internet
- Test command optimizer helps to improve test speed
- Capable of coding for any power supply testing applications
- Comprehensive hardware modules provide high accuracy and repetitive measurements
- High test throughput by system default test items
- Microsoft word based evaluation report or UUT characterization
- Cost effective
- Other hardware expandable upon request
- Windows 7/10 or higher based software
The 8000 test system uses a unique test command optimization technology to prevent repetitive control commands from being sent to the system hardware devices. This improve test speed dramatically and makes the Chroma 8000 an ideal choice for both high speed production applications as well as design verification.
The 8000 test system includes a sophisticated test executive which includes pre-written test items covering almost all industry standard power supply tests. User may also create new test items by using a special test item editing function. This gives users the capability to expand the test library unlimitedly.
PowerPro III also includes power ful report, statistic and management functions, making the s ys tem capable to generate var ious tes t document s and per forming s ys tem administration. Because the test and statistical repor ts are critically impor tant in modern factories for R/D evaluation, QA verification and production tests, these functions are an integral part of the system.
Working under Windows 7/10 the model 8000 provides test engineers with a dedicated power supply test system in an easy-to-learn Windows environment and allow access to resources provided by Windows.
The Model 8000 automatic power supply test system comes standard with an off-the-shelf test item library covering most industry standard power supply tests. Unlike traditional ATE software, users do not need to have programming language background to create new test items. Instead the Model 8000 allow users to use pre-compiled test items and to simplify defining test conditions and specifications.
The comprehensive test items cover 7 categories of power supply testing requirements. OUTPUT PERFORMANCE checks the general performances of the UUT. INPUT CHARACTERISTIC verifies the input parameters of a power supply. REGULATION tests the stability of the UUT under varying linein and loading changes. TIMING AND TRANSIENT measures the transient state during turn-on, turn-off or when events occurred. PROTECTION TESTS triggers the protection circuit of the power supply. Finally, the SPECIAL TEST and the SPECIAL FEATURES provides means to test the most sophisticated power supplies when unique test routines are needed.
1. DC output voltage
3. Peak-Peak noise
5. Current ripple*
7. In-test adjustment
9. Power fail signal
11. Extended measure
13. Overshoot voltage
14. Input Inrush current
16. Input peak current
18. Current harmonics against regulations
20. Input voltage ramp
22. AC cycle drop out
24. Current regulation
26. Total regulation
37. Short circuit
39. UV protection
41. OP protection
